Methods of stud connector as DIN Fittings Port Styles showed, please click the link. Styles connect as following: Tube to Metric Port ISO 9974 (DIN 3853) and ISO 6149; Tube to BSPP Port ISO 1179, Tube to UNF port ISO SAE J1926 (ISO 11926), Tube to Japanese BSPP port JIS B2351; Tube to NPT Port ANSI/ASME B 1.20.1; Tube to BSPT Port ISO 7/BS 21/DIN 2999-1.

Product Description

Part No.: JIS GAS MALE 60° CONE

Features:

➢Made of carbon steel, leak-proof and reliable.

➢Engineered for a secure and reliable seal, ensuring no fluid leaks.

➢Surface-treated for enhanced protection against rust and wear.

➢Conforms to JIC standards, making it suitable for various hydraulic systems.

➢Designed for quick and hassle-free assembly, reducing downtime.

Specifications

代号	螺纹 THREAD		O 形圈 O RING 胶垫 CAPTIVE		尺寸 DIMENSIONS
PART NO.	E	F	E 端	F 端	A	B	L	S1
1FB-04WD	9/16"X18	G1/4"X19	O011	WD-B04	10	12	30	19
1FB-06WD	11/16"X16	G3/8"X19	O012	WD-B06	11.2	12	33.5	22
1FB-06-04WD	11/16'X16	G1/4"X19	O012	WD-B04	11.2	12	31	19
1FB-08WD	13/16"X16	G1/2"X14	O014	WD-B08	12.8	14	40	27
1FB-08-06WD	13/16"X16	G3/8"X19	O014	WD-B06	12.8	12	35	22
1FB-10-08WD	1"X14	G1/4"X14	O016	WD-B08	15.5	14	43.5	32
1FB-12WD	1.3/16"x12	G3/4"x14	O018	WD-B12	17	16	47	32
1FB-16WD	1.7/16"X12	G1"X11	O021	WD-B16	17.5	18	51.5	41
1FB-20WD	1.11/16"X12	G1.1/4"X11	O025	WD-B20	17.5	20	55.5	50
